Efficient Effluent Management with GEA Slope Screens
GEA Slope Screens offer an innovative solution for effluent management, engineered by a Canadian-based company.
These slope screens are unique in that they have no moving parts, making them an efficient and reliable choice for separating solids from liquids in effluent. The separated liquid can be reused for tasks like wash-down water or for irrigation purposes on the farm. Using this recycled water for irrigation helps improve soil filtration rates, allowing pastures to be suitable for grazing much faster.
Available in screen sizes ranging from 4 to 8 feet, we provide customizable options based on your specific needs.
Maximize Resource Efficiency with the GEA SlopeScreen™
Dairy manure is a sustainable resource, and when managed effectively, it significantly boosts farm profitability and operational efficiency.
The GEA SlopeScreen™ enables farms to manage solids and liquids independently, offering flexibility in how these resources are utilized.
By separating the effluent, you can recycle liquid while effectively reducing the volume of solid manure.
- Configurable to suit individual farm needs, with interchangeable parts for easy customization.
- Available in 4,6 and 8 ft
- Self cleaning option, an automated sprayer washes the screen each time after use
- Standard screen sizes perform well in most environments, but custom sizes are available if needed.
- A simple design with minimal moving parts ensures easy maintenance and lower total cost of ownership (TCO).
- The SlopeScreen™ uses no electrical horsepower, while the SlopeScreen™ XP requires only a 1.5hp (1.1kW) motor for the new self cleaning screen feature.
- Built entirely from stainless steel, the SlopeScreen™ is designed to withstand even the most demanding and corrosive environments, ensuring long-term reliability.
Key Benefits of a GEA Slope Screen
Water Quality Separation: The GEA SlopeScreen™ can remove a substantial amount of solids, creating more storage room in effluent ponds while maintaining the nutrient content in the remaining liquid, which can be irrigated or transported for field application
Solids Management: Solids captured from the primary separation can be easily handled with the integrated XPress™ system, reducing moisture content in the fibers to approximately 80%, depending on operational conditions and manure composition.
